Series 16i/18i/160i/180i/160is/180is - TA Operators manual Page 419

Operators manual
PROGRAMMING
20. TWO–PATH CONTROL
FUNCTION
B–63004EN/02
398
In a CNC supporting two–path control, specified machining programs
can be copied between the two paths by setting bit 0 (PCP) of parameter
No. 3206 to 1. A copy operation can be performed by specifying either
a single program or a range. For information about operations, see
Section 9.10 in Part III.
Copy source number: 0001
Copy destination number: Not set
O0001 O0001
³
Copy source Copy destination
Copy source number: 0001
Copy destination 0010
O0001
O0010
³
Copy source Copy destination
Copy source number: 0001 to 0100
Copy destination number: Not set
O0001
O0010
O0100
O1000
O2000
O0001
O0010
O0100
³
³
³
Copy source Copy destination
Copy source number: 0001 to 0100
Copy destination 1000
O0001
O0010
O0100
O1000
O2000
O1001
O1001
O1002
³
³
³
Copy source Copy destination
20.8
COPYING A
PROGRAM
BETWEEN TWO
PATHS
Explanations
D Single–program copy
D Specified–range copy
Previous page
Next page
