Series 16i/18i/160i/180i/160is/180is - TA Operators manual Page 704

Operators manual

Page of 927

/ 927

OPERATION

B–63004EN/02

11. SETTING AND DISPLAYING DATA

685

NOTE

For the two–path control, the display may not be as shown

above. In some cases, only the coordinates along the axes

on tool post 1 are displayed due to the number of axes. In

that case, press the [ABS] soft key one more time to display

the coordinates along the axes on tool post 2.

ACTUAL POSITION O1000 N10010

X1 100.000

Z1 200.000

C1 300.000

Y1 400.000

(ACTUAL SPEED) F : 0 M M /

MIN

S : 0RPM

(PARTS COUNT) 114

(RUN TIME) 5H 3M

(CYCLE TIME) 0H 0M 6S

ABS

REL (OPRT

)

O2000 N20010

X2 500.000

Z2 600.000

C2 700.000

Y2 800.000

ALL HNDL

D Display with two–path control

(12 soft keys display unit)

(ACTUAL0

(ACTUAL SPEED) F : 0 M M /

MIN

S : 0RPM

(PARTS COUNT) 114

(RUN TIME) 5H 3M

(CYCLE TIME) 0H 0M 6S

MEM STOP *** *** 12:34:56

HEAD1

Bits 6 and 7 of parameter 3104 can be used to select whether the displayed

values include tool offset value and tool nose radius compensation.

On 7 soft keys display unit or the shared screen of 12 soft keys display

unit, only the coordinates for the first to fifth axes are displayed initially

whenever there are six or more controlled axes. Pressing the

[ABS] soft

key displays the coordinates for the sixth and subsequent axes. When six

or more controlled axes are used under two–path control, the coordinates

for path 1 are displayed initially on 7 soft keys display unit. Pressing the

[ABS] soft key displays the coordinates for path 2. On the shared screen

of 12 soft keys display unit, the tool post selection signal is used to select

the display for path 1 or 2.

D Two–path lathe control /

7 soft keys display unit

Explanations

D Display including

compensation values

D Displaying the sixth and

subsequent axes
