APPENDIXG. ALARM LIST
B–63004EN/02
826
Number ContentsMessage
221 ILLEGAL COMMAND IN
SYNCHR–MODE
Polygon machining synchronous operation and axis control or bal-
ance cutting are executed at a time. Modify the program.
224 RETURN TO REFERENCE POINT Not returned to reference point before cycle start.
225 SYNCHRONOUS/MIXED CONTROL
ERROR
(only with two path control only)
This alarm is generated in the following circumstances. (Searched for
during synchronous and mixed control command.
1 When there is a mistake in axis number parameter setting.
2 When there is a mistake in control commanded.
Modify the program or the parameter.
226 ILLEGAL COMMAND IN
SYNCHRO–MODE
(only with two path control only)
A travel command has been sent to the axis being synchronized in
synchronous mode. Modify the program or the parameter.
229 CAN NOT KEEP SYNCHRO–STATE
(only with two path control only)
This alarm is generated in the following circumstances.
1 When the synchro/mixed state could not be kept due to system
overload.
2 The above condition occurred in CNC devices (hardware) and
synchro–state could not be kept.
(This alarm is not generated in normal use conditions.)
231 FORMAT ERROR IN G10 OR L50 Any of the following errors occurred in the specified format at the pro-
grammable–parameter input.
1 Address N or R was not entered.
2 A number not specified for a parameter was entered.
3 The axis number was too large.
4 An axis number was not specified in the axis–type parameter.
5 An axis number was specified in the parameter which is not an
axis type.
6 An attempt was made to reset bit 4 of parameter 3202 (NE9) or
change parameter 3210 (PSSWD) when they are protected by a
password. Correct the program.
232 ILLEGAL AXIS COMMAND IN
HELICAL
Three or more axes were specified as helical axes in the helical inter-
polation mode.
233 DEVICE BUSY When an attempt was made to use a unit such as that connected via
the RS–232–C interface, other users were using it.
239 BP/S ALARM While punching was being performed with the function for controlling
external I/O units ,background editing was performed.
240 BP/S ALARM Background editing was performed during MDI operation.
244 P/S ALARM In the skip function activated by the torque limit signal, the number of
accumulated erroneous pulses exceed 32767 before the signal was
input. Therefore, the pulses cannot be corrected with one distribution.
Change the conditions, such as federates along axes and torque
limit, and try again.
245 T–CODE NOT ALOWED IN THIS
BLOCK
One of the G codes, G50, G10, and G04, which cannot be specified
in the same block as a T code, was specified with a T code.
246 ENCODE PROGRAM NUMBER
ERROR
During read of an encrypted program, an attempt was made to store
the program with a number exceeding the protection range.
(See parameter Nos. 3222 and 3223.)
247 ILLEGAL CODE USED FOR
OUTPUT
When an encrypted program is output, EIA is set for the punch code.
Specify ISO.
5010 END OF RECORD The end of record (%) was specified.
5016 ILLEGAL COMBINATION OF M
CODE
M codes which belonged to the same group were specified in a block.
Alternatively,an M code which must be specified without other M
codes in the block was specified in a block with other M codes.
