Series 16i/18i/160i/180i/160is/180is - TA Operators manual Page 860

Operators manual
INDEX
B–63004EN/02
i–1
ƠNumbersơ
8–digit program number, 147
ƠAơ
Absolute and incremental programming (G90, G91), 106
Actual feedrate display, 692
Address and specifiable value range for series 15 tape format, 337
Alarm and self–diagnosis functions, 559
Alarm display, 426, 560
Alarm history display, 562
Alarm list, 818
Altering a word, 637
Angular axis control / arbitrary axis control, 371
Applied software, 529
Arithmetic and logic operation, 292
Assembling, 529
Automatic erase CNC screen display, 767
Automatic inserting of sequence numbers, 666
Automatic operation, 417, 492
Automatic tool offset (G36, G37), 273
Auxiliary function, 128
Auxiliary function (M function), 129
Axis control function, 351
ƠBơ
B–axis control (G100, G101, G102, G103, G110), 361
Background editing, 657
Balance cut (G68, G69), 391
Battery for absolute pulse coder built into the motor (6 VDC), 793
Battery for separate absolute pulse coders (6VDC), 792
Battery in the intelligent terminal (3 VDC), 790
Branch and repetition, 298
ƠCơ
Canceling spindle positioning, 120
Canned cycle, 340
Canned Cycle (G90, G92, G94), 151
Canned cycle cancel (G80), 187
Canned cycle for drilling (G80–G89), 177
Canned drilling cycle formats, 343
Canned grinding cycle (for grinding machine), 189
Chamfering and corner R, 193
Change of words or addresses, 654
Changing of tool offset value (programmable data input ) (G10), 272
Changing workpiece coordinate system, 97
Character–to–codes correspondence table, 817
Characters and codes to be used for the pattern data input function,
408
Check by running the machine, 419
Checked by self–diagnostic screen, 563
Chuck and tailstock barriers, 549
Circular interpolation (G02, G03), 47
Circular threading (G35, G36), 71
Clearing the screen, 766
CNC control unit with 7.2″/8.4″ LCD, 432
CNC control unit with 9.5″/10.4″ LCD, 432
Command for machine operations – miscellaneous function, 27
Compensation function, 206
Conditional branch (IF statement), 299
Conditions for making a tool post interference check, 386
Connecting PCMCIA card attachment, 529
Constant lead threading (G32), 63
Constant surface speed control (G96, G97), 111
Continuous thread cutting, 68
Controlled axes, 33, 34
Conversational programming with graphic function, 671
Coordinate rotation (G68.1, G69.1), 276
Coordinate system, 92
Coordinate system on part drawing and coordinate system specified
by CNC – coordinate system, 19
Coordinate value and dimension, 105
Copying a program between two paths, 398, 660
Copying an entire program, 648
Copying part of a program, 649
Corner circular interpolation function (G39), 268
Correction in chamfering and corner arcs, 255
Counter input of offset value, 733
Counting a tool life, 126
Creating programs, 664
Creating programs in teach in mode (Playback), 668
Creating programs using the MDI panel, 665
Current block display screen, 700
Current position display, 426
Custom macro, 280
Cutting feed, 83
Cutting speed – spindle speed function, 25
Cylindrical interpolation (G07.1), 57
ƠDơ
Data input/output, 566
Data input/output on the ALL IO screen, 594
Data input/output using a memory card, 619
Data output, 429
Data setting for the tool post interference check function, 381
Decimal point programming, 108
Deleting a block, 639
