Series 16i/18i/160i/180i/160is/180is - TA Operators manual Page 923

Operators manual
#7 #6 #5 #4 #3 #2 #1 #0
5000 ASG
[ Input type ] Setting input
[ Data type ] Bit
ASG When the tool geometry/wear compensation function is available,
the compensation value changed by this function is:
0: Geometry compensation
1: Wear compensation
#7 #6 #5 #4 #3 #2 #1 #0
5040 MOP
(3)
[ Input type ] Parameter input
[ Data type ] Bit
MOP As for DI/DO signals of the Changing Active Offset Value with Manual
Move:
0: G297#4, G297#5, G297#6, and F297#5 are used.
(This setting cannot be used in PMC-SA1.)
1: G203#4, G203#5, G203#6, and F199#5 are used.
#7 #6 #5 #4 #3 #2 #1 #0
5041 ATP AOF
[ Input type ] Parameter input
[ Data type ] Bit
AOF When the manual feed-based active offset change mode is selected in a
reset state or a cleared state, the tool compensation:
0: Can be changed
1: Cannot be changed
Edit
Apprv.
Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series16i/18i/21i–TA/TB
Changing Active Offset Value
with Manual Move.
A
-78376
03 Jan.21.’02 Addition and modification of (3)
02 Feb.08.’01 T.Endo Overall revisio H.Kochiya
Jan.16.’01 T.Endo H.Kochiya
8/10
Previous page
Next page
