Series 16i/18i/160i/180i/160is/180is - TA Operators manual Page 924

Operators manual
The change of the tool compensation value follows the relation among this
parameter, the parameter LVC(No.5003#6), and the parameter TGC(No.5003#7).
AOF(No.5041#0)=0 AOF(No.5041#0)=1
LVC(No.5003#6=0) Can be changed
LVC(No.5003#6=1) Cannot be changed
TGC(No.5003#7=0) Can be changed
TGC(No.5003#7=1) Cannot be changed
Cannot be changed
ATP As for Changing Active Offset Value with Manual Move:
0: the tool compensation of the moving axis is changed.
(Whether Y-axis is the 3
rd
axis or the 4th axis follows the setting of
parameter Y03(5004#7)).
Moving axis Selected offset Status indication
X(1
st
) axis X axis compensation TOFS
Z(2
nd
) axis Z axis compensation TOFS
Y(3
rd
or 4
th
) axis
Y axis compensation
( In case Y axis offset is available )
TOFS
1: the tool compensation of the axis selected by DI signals which
are
AOFS1(G297#5) and AOFS2(G297#6) is changed.
Moving axis
AOFS2 AOFS1
Selected offset Status indication
0 0 X axis compensation OFSX
0 1 Z axis compensation OFSZ
1 1
Y axis compensation
( In case Y axis offset is available )
OFSY
Edit
Apprv.
Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series16i/18i/21i–TA/TB
Changing Active Offset Value
with Manual Move.
A
-78376
03 Jan.21.’02 Addition and modification of (3)
02 Feb.08.’01 T.Endo Overall revisio H.Kochiya
Jan.16.’01 T.Endo H.Kochiya
9/10
