Deleting tool data
Format Meaning of command
G10L72;
T-;
:
P-;
:
T- P-;
:
G11;
MO2(M30);
G10L72 : Starts the deletion of registered tool data.
T- : Delete tool data for the specified tool number.
P- : Delete all tool data for the specified pot number.
T- P- : Delete tool data for the specified tool number and
pot number.
G11 : Ends the deletion of setting data.
Example :
Tool data setting
N01 G10 L70 ;
N02 T01 P10 K11.0 R12.0 ;
N03 T02 P20 K21.0 R22.0 ;
N04 T03 P20 K31.0 R32.0 ;
N05 T04 P30 K32.0 R42.0 ;
N06 G11 ;
Tool data deleting
N11 G10 L72 ;
N12 T01 ; : Deletes the tool data (set in N02) corresponding to T01.
N13 P20 ; : Deletes the tool data (set in N03 and N04) corresponding to P02.
N14 T04 P30 ; : Deletes the tool data (set in N05) corresponding to T04 and P30.
N15 T04 P20 ; : Issues an alarm.
N16 G11 ;
