F.ALARM LIST APPENDIX B-63324EN/03
- 802 -
Number Message Contents
SR0807 PARAMETER SETTING ERROR An I/O interface option that has not yet been added on was
specified.
The external I/O device and baud rate, stop bit and protocol
selection settings are erroneous.
SR0808 DEVICE DOUBLE OPENED An attempt was made to open a device that is being
accessed.
SR0820 DR OFF(1) The data set ready input signal DR of the I/O device
connected to reader/punch interface 1 turned OFF.
SR0822 OVERRUN ERROR(1) The next character was received from the I/O device
connected to reader/punch interface 1 before it could read
a previously received character.
SR0823 FRAMING ERROR(1) The stop bit of the character received from the I/O device
connected to reader/punch interface 1 was not detected.
SR0824 BUFFER OVERFLOW(1) The NC received more than 10 characters of data from the
I/O device connected to reader/punch interface 1 even
though the NC sent a stop code (DC3) during data
reception.
SR0830 DR OFF(2) The data set ready input signal DR of the I/O device
connected to reader/punch interface 2 turned OFF.
SR0832 OVERRUN ERROR(2) The next character was received from the I/O device
connected to reader/punch interface 2 before it could read
a previously received character.
SR0833 FRAMING ERROR(2) The stop bit of the character received from the I/O device
connected to reader/punch interface 2 was not detected.
SR0834 BUFFER OVERFLOW(2) The NC received more than 10 characters of data from the
I/O device connected to reader/punch interface 2 even
though the NC sent a stop code (DC3) during data
reception.
SR0840 DR OFF(3) The data set ready input signal DR of the I/O device
connected to reader/punch interface 3 turned OFF.
SR0842 OVERRUN ERROR(3) The next character was received from the I/O device
connected to reader/punch interface 3 before it could read
a previously received character.
SR0843 FRAMING ERROR(3) The stop bit of the character received from the I/O device
connected to reader/punch interface 3 was not detected.
SR0844 BUFFER OVERFLOW(3) The NC received more than 10 characters of data from the
I/O device connected to reader/punch interface 3 even
though the NC sent a stop code (DC3) during data
reception.
SR0850 DR OFF(4) The data set ready input signal DR of the I/O device
connected to reader/punch interface 4 turned OFF.
SR0852 OVERRUN ERROR(4) The next character was received from the I/O device
connected to reader/punch interface 4 before it could read
a previously received character.
SR0853 FRAMING ERROR(4) The stop bit of the character received from the I/O device
connected to reader/punch interface 4 was not detected.
SR0854 BUFFER OVERFLOW(4) The NC received more than 10 characters of data from the
I/O device connected to reader/punch interface 4 even
though the NC sent a stop code (DC3) during data
reception.
SR0910 DEVICE DRIVER ERROR
(UNDEFINED)
An error occurred during device driver control.
SR0911 V-DEVICE DRIVER ERROR (DEVICE) An error occurred during device driver control.
SR0912 V-DEVICE DRIVER ERROR (OPEN) An error occurred during device driver control.
SR0913 V-DEVICE DRIVER ERROR
(COMMAND)
An error occurred during device driver control.
SR0914 V-DEVICE DRIVER ERROR (RANGE) An error occurred during device driver control.
SR0915 V-DEVICE DRIVER ERROR (TEST) An error occurred during device driver control.
SR0950 DRIVER ERROR (MEMORY CARD) An error occurred in the memory card device driver.
