Series 0i-PB Parameter manual Page 194

Parameter manual
4. DESCRIPTION OF PARAMETERS
B–63980EN/01
186
NRC According to the command of automatic return to the reference point
(G28), the machine is:
0: Moved along the C–axis to the reference point.
1: Not moved along the C–axis to the reference point.
This is validated when parameter CRM (No. 16362, #5) is set to 0.
#7 #6 #5 #4 #3 #2 #1 #0
16363 NDC NDB G91
[Data type] Bit
G91 For C–axis control, a G91 command is:
0: Disabled
1: Enabled
NDB Positioning under normal direction control is carried out:
0: According to the conventional specification.
1: By handling the C–axis angle immediately before the beginning of
the normal direction control mode, as an offset value.
NDC Positioning under normal direction control is carried out:
0: According to the conventional specification.
1: By handling the C–axis angle immediately before the beginning of
the normal direction control mode, as the direction normal to the next
traveling direction.
