4.1 Basic Instructions

The basic IL instruction set supports operations on BOOL, 8-bit (BYTE), 16-bit (INT, WORD, UINT) and 32-bit

(DINT, DWORD) variables. These instructions generally operate on an accumulator's content to generate a new value

for the same accumulator. The following instructions (sorted by functional group) are supported:

(a) Accumulator Instructions (Basic IL)

Mnemonic Description

LD_BOOL Load a value into the boolean accumulator.

LDN_BOOL Load the inverse of a value into the boolean accumulator.

LD_INT Load a single-precision integer value into the integer accumulator.

LD_ENO Load the enable output state, from the previously executed function, into the

boolean accumulator.

ST_BOOL Store the content of the boolean accumulator to a BOOL variable.

STN_BOOL Store the inverse of the boolean accumulator to a BOOL variable.

ST_INT Store the content of the integer accumulator to a single-precision integer (INT)

variable.

ST_UINT

Store the content of the integer accumulator to a single-precision integer (UINT)

variable.

ST_DINT Store the content of the integer accumulator to a double-precision integer (DINT)

variable.

ST_BYTE Store the content of the integer accumulator to a BYTE variable.

ST_WORD Store the content of the integer accumulator to a WORD variable.

ST_DWORD Store the content of the integer accumulator to a DWORD variable.

(b) Coil Instructions (Basic IL)

Mnemonic Description

S Store the content of the boolean accumulator to the Set Coil variable.

R Store the content of the boolean accumulator to the Reset Coil variable.
