Table 5.3.5 Displayed type and true type of I/O Units
Displayed I/O Unit ID True I/O Unit
CONNECTION UNIT 80 Connection Unit
OPERATOR PANEL 82 Connection Unit for Operators Panel
I/O-B3 83 I/O B3
IO UNIT-MODEL B 84
86
87
I/O Unit-MODEL A
PLC SERIES 90-30 45 PLC SERIES 90-30
POWER MATE / IO LINK BETA 4A Power Mate or I/O Link Beta
SERIES 0 50 Series 0
OPERATOR IF BOARD (MPG1) 53 Machine Operators Panel Interface
LINK CONNECTION UNIT 96 I/O Link Connecting Unit
I/O UNIT-MODEL B 9E I/O Unit-MODEL B
R-J MATE 61 R-J Mate
CONNECTOR PANEL MODULE A9 I/O module for connector panel
OPERATOR PANEL A1 AA I/O module for operator's panel
OPERATOR I/F BOARD (MPG3) 6B Operator Interface(with MPG)
LOADER I/O AF I/O Board for Loader
ROBOCUT DIF B0 DIF Board for ROBOCUT
ROBOCUT MIF B1 MIF Board for ROBOCUT
I/O CARD B2 I/O board
ROBOSHOT I/O CARD A B3 I/O for ROBOSHOT
LOADER I/O (MATRIX) B4 I/O Board for Loader(Matrix)
PROCESS I/O FA B5 Process I/O for R-J3
PROCESS IO 89 Process I/O for R-X
I/O LINK ADAPTER 8B I/O Link adapter
ROBOT CONTROLLER 52 Controller for R-X
PLC SERIES 90 54 PLC SERIES 90
OPERATOR PANEL 95 I/O for Series 0
LASER OSCILLATOR 97 Laser Oscillator
FIXED I/O TYPE A 98 I/O for Robot Type A
FIXED I/O TYPE B 99 I/O for Robot Type B
AS-I CONVERTER 77 AS-i Converter
OPERATOER PANEL B A8 I/O Module(for Operator Panel 48/32)
MACHINE OPERATOER PANEL A A8 I/O Module(for Machine Operator Panel of 0 Type)
CONNECTION UNIT C1 (MPG) A8 Connection Unit C1(with MPG)
MACHINE OPERATOER PANEL B A8 I/O Module (for Machine Operator Panel )
I/O MODULE WITH LCD A8 LCD display embedded I/O
UNKNOWN UNIT - Unsupported I/O Unit
