FANUC PMC-MODEL SD7

Programming Manual

01 01.11.26

Hanaoka

New

A-78550E

EDIT DATE DESIG.

DESCRIPTION

312/

316

TITLE

DRAW.NO.

B ALARM MESSAGE LIST

B.1 PMC ALARMS/SYSTEM ALARMS

Alarm number Faulty location/corrective action Contents

ER01 PROGRAM DATA ERROR 1) Re-input the sequence program.

2) Replace the master printed

circuit board.

The sequence program is invalid.

ER02 PROGRAM SIZE OVER 1) Reduce the sequence program.

2) Contact FANUC to have a larger

number-of-Ladder-steps option

specified.

The sequence program is too large.

The sequence program is invalid.

ER03 PROGRAM SIZE ERROR

(OPTION)

1) Reduce the sequence program.

2) Contact FANUC to have a larger

number-of-Ladder-steps option

specified.

The sequence program exceeds the size

specified by the number-of-Ladder-steps

option.

ER04 PMC TYPE UNMATCH Using an offline programmer,

change the sequence program to

that for the correct PMC type.

The setting of the type in the sequence

program differs from the actual type.

ER06 PMC CONTROL

SOFTWARE TYPE UNMATCH

Contact FANUC to specify certain

PMC type.

The combination of CNC system

configuration and PMC type is invalid.

(Example: PMC-SB5 is used for a 3-path

CNC system.)

ER07 NO OPTION(LADDER

STEP)

1) Restore the backed up CNC

parameter data.

2) Check the data sheet and re-

input the CNC parameters.

Contact FANUC to specify a

number-of-Ladder-steps option

of the necessary size.

No number-of-Ladder-steps option is found.

ER08 OBJECT UNMATCH

1) Contact FANUC.

An unsupported function is used in the

sequence program.

ER09 PMC LABEL CHECK

ERROR

PLEASE TURN ON POWER

AGAIN WITH PUSH ’O’&’Z’.

(CLEAR PMC SRAM)

1) Press and hold down the ’O’ and

’Z’ key combination, and turn the

CNC back on.

2) Replace the backup battery.

3) Replace the master printed

circuit board.

With a change in the PMC type, for

example, the retention-type memory of the

PMC must be initialized.

ER10 OPTION AREA NOTHING

(xxxx)

Contact FANUC to reconfigure the

PMC management software.

The PMC management software is not

loaded correctly.

ER11 OPTION AREA

NOTHING(xxxx)

Contact FANUC to reconfigure the

PMC management software.

The PMC C board management software is

not loaded correctly.
