  2. FANUC Series 16i/160i-LB,LPB Pulse Power Feedback Function

FANUC Series 16i/160i-LB,LPB Pulse Power Feedback Function Additional Manual Page 7

Additional Manual
EDIT
DATE DESIGN
DESCRIPTION
TITLE
Pulse Power Feedback Function
A-81053-080
Page
６/16
01 04.09.14 M.Andou New registration
FANUC LTD
DR
A
W
No.
02 05.11.08 M.Andou Change of approx. power monitor
Table 2-5. Pc=1500W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
155 152 142 103 16 0 0 0
25%
393 390 381 405 317 214 167 54
35%
550 545 523 568 508 399 370 279
50%
788 781 770 771 781 688 698 646
70%
1096 1087 1065 1060 1109 1045 1071 1032
90%
1396 1388 1368 1375 1384 1363 1370 1356
Table 2-6. Pc=1750W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
180 179 168 131 42 2 0 0
25%
453 451 456 468 394 289 256 135
35%
636 629 617 661 612 517 505 413
50%
912 902 896 910 945 867 882 828
70%
1269 1259 1245 1255 1319 1270 1290 1242
90%
1618 1610 1606 1612 1620 1602 1608 1595
Table 2-7. Pc=2000W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
205 209 196 158 74 20 0 0
25%
520 516 525 527 467 382 364 246
35%
730 722 721 744 715 647 656 570
50%
1048 1034 1031 1053 1091 1055 1064 1028
70%
1459 1450 1440 1454 1536 1516 1520 1480
90%
1863 1856 1877 1882 1883 1869 1871 1860
Table 2-8. Pc=2700W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
250 262 252 218 138 84 52 0
25%
641 637 666 677 646 597 610 581
35%
916 891 920 942 968 938 961 981
50%
1306 1275 1294 1326 1408 1428 1431 1480
70%
1306 1275 1294 1326 1408 1428 1431 1480
90%
1306 1275 1294 1326 1408 1428 1431 1480
Table３ C2000-E (Level up type, B321,B322) standard data table
Previous page
Next page
