Revision of Spindle Software 9D50 Edition J Additional Manual Page 1
Additional Manual
TITLE
DRAW
.
No.
001/1
Page
FANUC LTD
DESCRIPTION DESIGN DATE
EDIT
Revision of αi series Spindle
software 9D50 edition J
A
-63448E-106
M. Niwa 04.04.09 01
Revision of Spindle software 9D50 edition J
1. General
αi / βi series Spindle software 9D50 series was revised as follows.
2. ROM series, edition and applied PCB
ROM drawing No. ROM edition SPM specification Applied PCB
A06B-6111-H550
9D50
edition J(10)
A06B-6111-Hxxx#H550
A06B-6112-Hxxx#H550
A06B-6121-Hxxx#H550
A06B-6122-Hxxx#H550
A20B-2100-0800
A20B-2100-0801
A06B-6134-Hxxx#A
A20B-2101-0012+A20B-2902-670
A20B-2101-0013+A20B-2902-670
3. Contents of modifications
ROM edition Contents of modifications
9D50/J
In case soft start / stop signal is always on, if emergency stop is released just after a
spindle motor is stopped by emergency stop, the motor accelerates without soft start.
This trouble is corrected.
Incidentally, this trouble doesn’t occur in general usage because emergency stop
release just after spindle stop is irregular operation.
