8.1 MENU FOR MACHINING TYPE SELECTING
As a menu for selecting a machining type, following soft-keys are
displayed.
1) Soft-key menu #1 for FANUC standard machining type
GUIDNC SINGLE CYCLE
2) Soft-key menu #2 for FANUC standard machining type
By pushing a [CYCLE] in the above soft-key group #1, detailed
menu of cycle motions as follows is displayed.
BAR
ROUGH
BAR
FINISH
THREAD GROOVE GROOVE
TRAPE.
ROUGH
GROOVE
TRAPE.
FINISH
CENTER DRILL REAM BORE
By pushing a [ + ], 2nd menu as follows is displayed.
TAP CUST.1 CUST.2 CUST.3 CUST.4 CUST.5
3) Soft-key menu for custom-made machining type
In the above 2nd menu, machining type menu prepared for
custom-made process are displayed.
NOTE
1 In order to use these custom-made machining
processes, corresponding parameter must be set
as follows.
Parameter No.9640
#0bit = 1 : Custom-made process 1 is available
= 0 : Not available
#1bit = 1 : Custom-made process 2 is available
= 0 : Not available
#2bit = 1 : Custom-made process 3 is available
= 0 : Not available
#3bit = 1 : Custom-made process 4 is available
= 0 : Not available
#4bit = 1 : Custom-made process 5 is available
= 0 : Not available
2 It is not always needed to use all of the above
custom-made machining processes, and at the
time of using a part of them, menu soft-keys are
displayed close to left end as the following sample.
Sample) Custom-made 2 and 4 are available
CUST.2 CUST.4
