0i/0i Mate - Model C Parameter manual Page 158

Parameter manual
4.DESCRIPTION OF PARAMETERS B-64120EN/01
- 146 -
DAL Absolute position
0 : The actual position displayed takes into account tool length
offset (M series) or tool offset (T series).
1 : The programmed position displayed does not take into account
tool length offset (M series) or tool offset (T series).
NOTE
When tool geometry compensation of the T system
is to be performed by shifting the coordinate
system (with bit 4 (LGT) of parameter No.5002 set
to 0), the programmed position, ignoring tool offset,
is displayed (with this parameter set to 1), but the
programmed position, ignoring tool geometry
compensation, cannot be displayed.
DAC Absolute position
0 : The actual position displayed takes into account cutter
compensation (M series) or tool nose radius compensation (T
series).
1 : The programmed position displayed does not take into account
cutter compensation (M series) or tool nose radius compensation
(T series).
#7 #6 #5 #4 #3 #2 #1 #0
DPS PCF DPF
3105
SMF DPS PCF DPF
[Data type] Bit
DPF Display of the actual speed on the current position display screen,
program check screen and program screen (MD1 mode)
0 : Not displayed
1 : Displayed
PCF Addition of the movement of the PMC-controlled axes to the actual
speed display
0 : Added
1 : Not added
NOTE
For each setting, movement along any axis other
than those controlled by the CNC (see the
description of parameter No. 1010) is not reflected
in the actual speed display.
DPS Actual spindle speed and T code
0 : Not always displayed
1 : Always displayed
