0i/0i Mate - Model C Parameter manual Page 207

Parameter manual

Page of 414

/ 414

B-64120EN/01 4.DESCRIPTION OF PARAMETERS

- 195 -

#7 #6 #5 #4 #3 #2 #1 #0

SIM

3713

NOTE

When this parameter has been set, the power must

be turned off before operation is continued.

[Data type] Bit

SIM In multi-spindle control, when address P is used for spindle selection

(bit 3 of parameter No. 3703 = 1), and an axis move command and S

command are specified in the same block:

0 : The S command becomes valid after an axis movement is

completed.

1 : The S command becomes valid at the same time when an axis

movement is made.

#7 #6 #5 #4 #3 #2 #1 #0

3715 NSAx

[Data type] Bit axis

NSAx This parameter specifies an axis for which confirmation of the spindle

speed reached signal (SAR) is unnecessary when a move command is

executed for the axis. When a move command is issued only for an

axis for which 1 is set in this parameter, the spindle speed reached

signal (SAR) is not checked.

0 : Confirmation of SAR is necessary.

1 : Confirmation of SAR is unnecessary.

3730 Data used for adjusting the gain of the analog output of spindle speed

[Data type] Word

[Unit of data] 0.1 %

[Valid data range] 700 to 1250

Set data used for adjusting the gain of the analog output of

spindle speed.

[Adjustment method]

(1) Assign standard value 1000 to the parameter.

(2) Specify the spindle speed so that the analog output of the spindle

speed is the maximum voltage (10 V).

(3) Measure the output voltage.

(4) Assign the value obtained by the following equation to parameter

No.3730.

10 (V)

Set value=

Measured data (V)

×1000

(5) After setting the parameter, specify the spindle speed so that the

analog output of the spindle speed is the maximum voltage.

Confirm that the output voltage is 10V.
