0i/0i Mate - Model C Parameter manual Page 245

Parameter manual
B-64120EN/01 4.DESCRIPTION OF PARAMETERS
- 233 -
5030
Minimum grinding wheel diameter in minimum grinding wheel diameter
check
[Data type] 2-word
[Unit of data]
Input increment IS-A IS-B IS-C Unit
Millimeter input 0.01 0.001 0.0001 mm
Inch input 0.001 0.0001 0.00001 inch
[Valid data range]
Input increment IS-A, IS-B IS-C
Millimeter input -999999 to 999999 -9999999 to 9999999
Inch input -999999 to 999999 -9999999 to 9999999
If the compensation value corresponding to an offset number specified
by an H code is smaller than the minimum grinding wheel diameter
specified in this parameter during compensation with G43 or G44, the
signal F0065#3 GWLF is output to the PMC.
NOTE
This is a parameter for cylindrical grinding
machines.
#7 #6 #5 #4 #3 #2 #1 #0
OWD
5040
NOTE
When this parameter has been set, the power must
be turned off before operation is continued.
[Data type] Bit
OWD In radius programming (bit 1 (ORC) of parameter No. 5004 is set to
1),
0 : Tool offset values of both geometry compensation and wear
compensation are specified by radius.
1 : Tool offset value of geometry compensation is specified by
radius and tool offset value of wear compensation is specified by
diameter, for an axis of diameter programming.
#7 #6 #5 #4 #3 #2 #1 #0
CRS
5041
NM2 UMD
[Data type] Bit
UMD If a program contains no D command in cutter compensation C:
0 : Compensation data is not updated.
1 : If G41 or G42 command is present, the value of modal D is used
as a compensation number to update compensation data.
