0i/0i Mate - Model C Parameter manual Page 288

Parameter manual
4.DESCRIPTION OF PARAMETERS B-64120EN/01
- 276 -
5410
Angular displacement used when no angular displacement is specified for
coordinate system rotation
The following parameter can be set at "Setting screen".
[Data type] 2-word
[Unit of data] 0.001 degrees
[Valid data range] -360000 to 360000
This parameter sets the angular displacement for coordinate system
rotation. When the angular displacement for coordinate system
rotation is not specified with address R in the block where G68 is
specified, the setting of this parameter is used as the angular
displacement for coordinate system rotation.
5411
Magnification used when scaling magnification is not specified
The following parameter can be set at "Setting screen".
[Data type] 2-word
[Unit of data] 0.001, 0.00001, or 0.0000001 times (selected by bit 7 (SCR) of
parameter No. 5400) or bit 0 (S8D) of parameter No. 5402 (M series))
[Valid data range] 1 to 999999 (when 0.001 or 0.00001 times is selected)
1 to 99999999 (when 0.0000001 times is selected) (M series)
This parameter sets the scaling magnification. This setting value is
used when a scaling magnification (P) is not specified in the program.
NOTE
Parameter No.5421 becomes valid when scaling
for every axis is valid. (XSC, #6 of parameter
No.5400 is "1".)
5421
Scaling magnification for every axis
The following parameter can be set at "Setting screen".
[Data type] 2-word axis
[Unit of data] 0.001, 0.00001, or 0.0000001 times (selected by bit 7 (SCR) of
parameter No. 5400) or bit 0 (S8D) of parameter No. 5402 (M series))
[Valid data range] -999999 to -1, 1 to 999999 (when 0.001 or 0.00001 times is selected)
-99999999 to -1, 1 to 99999999 (when 0.0000001 times is selected)
(M series)
This parameter sets the scaling magnification for every axis.
