4.DESCRIPTION OF PARAMETERS B-64120EN/01

- 292 -

#7 #6 #5 #4 #3 #2 #1 #0

6010 *7 *6 *5 *4 *3 *2 *1 *0

#7 #6 #5 #4 #3 #2 #1 #0

6011 =7 =6 =5 =4 =3 =2 =1 =0

#7 #6 #5 #4 #3 #2 #1 #0

6012 #7 #6 #5 #4 #3 #2 #1 #0

#7 #6 #5 #4 #3 #2 #1 #0

6013 [7 [6 [5 [4 [3 [2 [1 [0

#7 #6 #5 #4 #3 #2 #1 #0

6014 ]7 ]6 ]5 ]4 ]3 ]2 ]1 ]0

[Data type] Bit

These parameters are used for input/output with EIA codes.

The numeral of a suffix indicates the bit position in a code.

*0 to *7 : Set the hole pattern of an EIA code indicating *.

=0 to =7 : Set the hole pattern of an EIA code indicating =.

#0 to #7 : Set the hole pattern of an EIA code indicating #.

[ 0 to [ 7 : Set the hole pattern of an EIA code indicating [.

] 0 to ] 7 : Set the hole pattern of an EIA code indicating ].

0 : Corresponding bit is 0

1 : Corresponding bit is 1.

6030 M code that calls the program entered in file

[Data type] 2-word

[Valid data range] 0, and 1 to 255

This parameter sets an M code that calls the program entered in a file.

NOTE

The M code is judged to be M198 when zero is

specified as the setting value.
