4.DESCRIPTION OF PARAMETERS B-64120EN/01
- 336 -
4.41 PARAMETERS OF SOFTWARE OPERATOR'S PANEL
#7 #6 #5 #4 #3 #2 #1 #0
7200 OP7 OP6 OP5 OP4 OP3 OP2 OP1
[Data type] Bit
OP1 Mode selection on software operator's panel
0 : Not performed
1 : Performed
OP2 JOG feed axis select and JOG rapid traverse buttons on software
operator's panel
0 : Not performed
1 : Performed
OP3 Manual pulse generator's axis select and manual pulse generator's
magnification switches on software operator's panel
0 : Not performed
1 : Performed
OP4 JOG speed override and rapid traverse override switches on software
operator's panel
0 : Not performed
1 : Performed
OP5 Optional block skip, single block, machine lock, and dry run switches
on software operator's panel
0 : Not performed
1 : Performed
OP6 Protect key on software operator's panel
0 : Not performed
1 : Performed
OP7 Feed hold on software operator's panel
0 : Not performed
1 : Performed
#7 #6 #5 #4 #3 #2 #1 #0
7201 JPC
[Data type] Bit
JPC For the name of a general-purpose switch function on the software
operator's panel, the use of full-size characters is:
0 : Not allowed.
1 : Allowed.
