AC spindle motor model αiI 15/10000HV
Output characteristics (Applied spindle amplifier: αiSP 15HV)
PLAN
0
3
6
9
12
15
0 2000 4000 6000 8000 10000
Note) Maximum output power during acceleration to select α
iPS is 15.6kW.
(This is not a guaranteed value but a guideline.)
AA-221442/01E
■Low speed winding (Star connection)
Output (kW)
Motor speed (min
-1
)
S1(continuous) operating zone
57.3Nm
13kW
S2 30min, S3 60％ operating zone
9kW
82.8Nm
7.5kW
11kW
1500
