14. FUNCTIONS TO SIMPLIFY
G26I r J θ K n ;
This G26 punches n pieces of equally divided points on the
circumference, starting with the point which forms angle θ with the
reference to X axis on the circumference having radius r with the present
tool position or the position commanded by G72 being set as the circle
r : Radius of circle
The unit is input unit.
It is commanded by a positive number.
θ : Angle between the first punch point and +X axis
This unit is input unit (deg), and the counterclockwise direction is
commanded as positive.
n : Number of punch points ("1 to "9999)
Counterclockwise punching is made by a positive number, while
clockwise punching is made by a negative number.
Bolt Hole Circle (G26)
