PROGRAMMING16. CUSTOM MACRO
By setting an M code number used to call a macro program in a parameter,
the macro program can be called in the same way as with a simple call
M50 A1.0 B2.0 ;
Parameter 6080 = 50
By setting an M code number from 1 to 255 used to call a custom macro
program (9020 to 9029) in the corresponding parameters (No.6080 to
No.6089), the macro program can be called in the same way as with G65.
Program number Parameter number
As with a simple call, a number of repetitions from 1 to 9999 can be
specified at address L.
As with a simple call, two types of argument specification are available:
Argument specification I and argument specification II. The type of
argument specification is determined automatically according to the
S An M code used to call a macro program must be specified at the start
of a block.
S In a macro called with a G code or in a program called as a subprogram
with an M or T code, no macros can be called using an M code. An
M code in such a macro or program is treated as an ordinary M code.
Macro Call Using
an M Code
numbers and program
D Argument specification
