PROGRAMMING
18. HIGH SPEED CUTTING
FUNCTIONS
B–63684EN/01
314
This function is designed for high–speed precise machining. With this
function, the delay due to acceleration/deceleration and the delay in the
servo system which increase as the feedrate becomes higher can be
suppressed.
The tool can then follow specified values accurately and errors in the
machining profile can be reduced.
This function becomes effective when advanced preview control mode is
entered.
For details, refer to the relevant manual published by the machine tool
builder.
P1 : Turn on advanced preview control mode.
P0 : Turn off advanced preview control mode.
G08 P_
In advanced preview control mode, the following functions are available:
(1) Linear acceleration/deceleration before interpolation
(2) Automatic corner deceleration function
For details on the above functions, see the descriptions of the functions.
For functions
(1) and (2), specific parameters are provided.
Advanced preview control mode is canceled by reset.
Specify G08 code only in a block on the interpolation mode.
In the advanced preview control mode, the optional functions listed below
can be specified.
It cannot be used for the function to specify punching.
NOTE
To use a function other than the following optional functions,
turn the advanced preview control mode off, specify the
desired function, then turn the mode on again.
18.2
ADVANCED
PREVIEW CONTROL
(G08)
Format
Explanations
D Available functions
D Reset
Limitations
D G08 command
D Functions that can be
specified
