When the cycle start pushbutton is pressed, the tool executes one
operation then stops. By pressing the cycle start again, the tool executes
the next operation then stops. The program is checked in this manner (See
Fig.1.4.1 (c) Single block
Change cause by machine
The tool remains stopped, and only the
positional displays of the axes change.
Fig.1.4.2 Machine lock
When automatic running is placed into the auxiliary function lock mode
during the machine lock mode, all auxiliary functions (tool replacement,
coolant on/off, etc.) are disabled (See Section III–5.1).
D Single block
How to View the
Running the Machine
D Machine lock
D Auxiliary function lock
