OPERATION
B–63684EN/01
4. AUTOMATIC OPERATION
407
While an automation operation is being performed, a program input from
an I/O device connected to the reader/punch interface can be executed and
output through the reader/punch interface at the same time.
Simultaneous Input/Output
1 Search for the program (file) to be output and executed.
2 Press the REMOTE switch on the machine operator’s panel to set
RMT mode. For details of the use of the REMOTE switch, refer to the
relevant manual supplied by the machine tool builder.
3 Set the simultaneous output operation mode select signal to 1.
4 Press the cycle start switch.
5 Program output and execution is performed on a block–by–block
basis.
PROGRAM CHECK F0001 N00100
N100 X100. Y100. ;
N200 G01 X50. Y50. ;
N300 G00 X0 Y0 ;
(RELATIVE) (DIST TO GO) G00 G17 G90
X 100.000 X 0.000 G22 G94 G21
Y 100.000 Y 0.000 G40 G49 G80
Z 0.000 Z 0.000 G98 G50 G67
A 0.000 A 0.000 B
C 0.000 C 0.000 H M
HD.T NX.T D M
F S M
ACT.F SACT REPEAT
RMT STRT MTN *** *** 21:20:05
[ ABS ] [ REL ] [ ] [ ] [ (OPRT) ]
Program check screen
When a program is displayed, three blocks are displayed: the block
currently being executed and the next two to be executed. When the single
block function is selected, only the block currently being executed is
displayed.
Any comment enclosed between a control–out mark (() and control–in
mark ()) within a block is not displayed.
1 Search for the program (file) to be output and executed.
2 Press the REMOTE switch on the machine operator’s panel to set
RMT mode. For details of the use of the REMOTE switch, refer to the
relevant manual supplied by the machine tool builder.
3 Set the simultaneous output operation mode select signal to 1.
4 Press the cycle start switch.
5 Program output and execution is performed on a block–by–block
basis.
4.4
SIMULTANEOUS
INPUT/OUTPUT
Procedure
D Basic simultaneous
input procedure
D
Basic simultaneous output
procedure
