8. DATA INPUT/OUTPUT
Unnecessary saved files can be deleted from a memory card.
1 Press the rightmost soft key (next–menu key) on the ALL IO
screen, described in Section 8.11.1.
2 Press soft key
3 Place the CNC in the emergency stop state.
4 When a memory card is inserted, the state of the memory card is
displayed as shown below.
S 0 T0000
EDIT **** - - EMG- - 12: 15: 00
[FORMAT] [ SAVE ] [ LOAD ] [DELETE] [ ]
READ/PUNCH(M–CARD) O1234 N12345
512K byte 2. 000M byte S- RAM
File ( 1/ 1)
SRAM0_5A. FDB 524288 byte 01/ 01/ 23
Select : All data
5 Press soft key [DELETE].
6 With cursor keys
and , select the file to be deleted from the
7 After checking the file selection, press soft key
8 As detection is being performed, the message ”DELETING” blinks in
the message field.
9 Upon the completion of deletion, the message ”COMPLETED” is
displayed in the message field
An SRAM of 1M bytes or more will contain multiple files. To
delete the contents of such an SRAM, delete all the
