OPERATION8. DATA INPUT/OUTPUT
B–63684EN/01
540
Batch input/output with a memory card
On the ALL IO screen, different types of data including part programs,
parameters, offset data, pitch error data, custom macros, and workpiece
coordinate system data can be input and output using a memory card; the
screen for each type of data need not be displayed for input/output.
Memory card ALL IO screen²
³
Data item name
Part program
Parameter
Offset data
Pitch error data
Custom macro
Workpiece coordinate system
data
(additional coordinate systems)
1 Press the EDIT switch on the machine operator’s panel.
2 Press function key
SYSTEM
.
3 Press the rightmost soft key
(next–menu key) several times.
4 Press soft key
[ALL IO]. The screen shown below is displayed.
PROG (OPRT)OFFSETPARAM
READ/PUNCH (PROGRAM)
No. FILE NAME SIZE DATE
O0001 N00001
*0001 O0222 332010 01–04–06
*0002 O1003 334450 01–05–04
*0003 MACROVAR.DAT 653400 01–05–12
*0004 O0002 341205 01–05–13
[PROGRAM]
*O0001 O0002 O0003 O0005 O0100 O0020
*O0006 O0004 O0110 O0200 O2200 O0441
*O0330
>
EDIT 10:07:37
*** **** *** ****
Upper part : Directory of files on the memory card
Lower part : Directory of registered programs
5 With cursor keys
and , the user can choose between upper
part scrolling and lower part scrolling. (An asterisk (*) displayed at
the left edge indicates the part for which scrolling is possible.)
: Used for memory card file directory scrolling.
: Used for program directory scrolling.
6 With page keys
and , scroll through the file directory or
program directory.
Procedure
