11. SETTING AND DISPLAYING DATA
591
Displays the following positions on a screen : Current positions of the
tool in the workpiece coordinate system, relative coordinate system, and
machine coordinate system, and the remaining distance. The relative
coordinates can also be set on this screen. See subsection 11.1.2 for the
procedure.
Procedure for displaying overall position display screen
1 Press function key
POS
.
2 Press soft key
[ALL].
(RELATIVE)
X 246.912
Y 913.780
C 1578.246
(ABSOLUTE)
X 123.456
Y 456.890
C 789.123
(MACHINE)
X 0.000
Y 0.000
C 0.000
(DISTANCE TO GO)
X 0.000
Y 0.000
C 0.000
MEM **** *** *** 09:06:35
[ ABS ][ REL ][ ALL ][ HNDL ][ OPRT ]
ACTUAL POSITION O1000 N00010
PART COUNT 5
RUN TIME 0H15M CYCLE TIME 0H 0M38S
ACT.F 3000 MM/M S 0 T0000
The current positions of the tool in the following coordinate systems are
displayed at the same time:
S Current position in the relative coordinate system
(relative coordinate)
S Current position in the work coordinate system
(absolute coordinate)
S Current position in the machine coordinate system
(machine coordinate)
S Distance to go (distance to go)
The distance remaining is displayed in the MEMORY or MDI mode. The
distance the tool is yet to be moved in the current block is displayed.
The least command increment is used as the unit for values displayed in
the machine coordinate system. However, the least input increment can
be used by setting bit 0 (MCN) of parameter 3104.
On the Twelve–soft key type LCD, only the coordinates for the first to
fifth axes are displayed initially whenever there are six or more controlled
axes. Pressing the
[ALL] soft key displays the coordinates for the sixth
and subsequent axes.
