11. SETTING AND DISPLAYING DATA
611
EDIT *** *** *** *** 16:52:13
[INS–TM][ ][ ][ ][ ]
PROGRAM O0280 N0000
O0280 (SHAFT XSF303) (1H10M59S)
N10 G92 X100. Y10. ;
N20 S1500 M03 ;
N30 G00 X20.5 Y5. T0101 ;
N40 G01 Y–10. F25. ;
N50 G02 X16.5 Y–12. R2. ;
N60 G01 X40. ;
N70 X42. Y–13. ;
N80 Y–50. ;
N90 X44. Y–51. ;
N100 X80. ;
PROGRAM O0280 N0000
SYSTEM EDITION B001 – 05
PROGRAM NO. USED : 8 FREE : 55
MEMORY AREA USED : 2480 FREE : 5760
PROGRAM LIBRARY LIST
O0260 (SHAFT XSF302 ):(001H15M59S)
O0280 (SHAFT XSF303 ):( )
>_
EDIT **** *** *** 16:52:13
[ PRGRM ][ LIB ][ ][ ][ (OPRT) ]
Example 3: Program directory screen when inserted machining time data
does not conform to the format hhhHmmMssS (3–digit number followed
by H, 2–digit number followed by M, and 2–digit number followed by S,
in this order)
The machining time display field is blank.
If an incorrect machining time is calculated (such as when a reset occurs
during program execution), reexecute the program to calculate the correct
machining time. If the machining time display screen displays multiple
programs with the same program number, select the machining time of the
latest program number for insertion into the program.
D Correcting the
machining time
