11. SETTING AND DISPLAYING DATA
613
PROGRAM NO. USED
PROGRAM NO. USED : The number of the programs registered
(including the subprograms)
FREE : The number of programs which can be
registered additionally.
MEMORY AREA USED
MEMORY AREA USED : The capacity of the program memory in which
data is registered (indicated by the number of
characters).
FREE : The capacity of the program memory which
can be used additionally (indicated by the
number of characters).
Program Nos. registered are indicated.
The soft key [DIR] can be used to switch between the program name
screen (Fig. 11.3.1 (a)) and the program size and program update date
screen (Fig. 11.3.1 (b)). The update date is also changed when the
program number is changed.
O0001 (MACRO–GCODE.MAIN)
O0002 (MACRO–GCODE.SUB1)
O0010 (TEST–PROGRAM.ARTHMETIC NO.1)
O0020 (TEST–PROGRAM.F10–MACRO)
O0040 (TEST–PROGRAM.OFFSET)
O0050
O0100 (INCH/MM CONVERT CHECK NO.1)
O0200 (MACRO–MCODE.MAIN)
> _
EDIT **** *** *** 16:05:59
[ PRGRM ][ DIR ][ ][ ][ (OPRT) ]
PROGRAM DIRECTORY O0001 N00010
PROGRAM(NUM.) MEMORY(CHAR.)
USED: 60 3321
FREE: 2 429
Fig. 11.3.1 (a)
O0001 360 1966–06–12 14:40
O0002 240 1966–06–12 14:55
O0010 420 1966–07–01 11:02
O0020 180 1966–08–14 09:40
O0040 1140 1966–03–25 28:40
O0050 60 1966–08–26 16:40
O0100 120 1966–04–30 13:11
> _
EDIT **** *** *** 16:52:13
[ PRGRM ][ DIR ][ ][ ][ (OPRT) ]
PROGRAM DIRECTORY O0001 N00010
PROGRAM(NUM.) MEMORY(CHAR.)
USED: 17 4320
FREE: 46 3960
Fig. 11.3.1 (b)
Explanations
D Details of memory used
D Program library list
