OPERATION11. SETTING AND DISPLAYING DATA
B–63684EN/01
622
4 Move the cursor to the item to be changed by pressing cursor keys
, , , or .
5 Enter a new value and press soft key
[INPUT].
Setting whether parameter writing is enabled or disabled.
0 : Disabled
1 : Enabled
Setting to perform TV check.
0 : No TV check
1 : Perform TV check
Setting code when data is output through reader puncher interface.
0 : EIA code output
1 : ISO code output
Setting a program input unit, inch or metric system
0 : Metric
1 : Inch
Using channel of reader/puncher interface.
0 : Channel 0
1 : Channel 1
2 : Channel 2
3 : Channel 3
Setting of whether to perform automatic insertion of the sequence number
or not at program edit in the EDIT mode.
0 : Does not perform automatic sequence number insertion.
1 : Perform automatic sequence number insertion.
Setting the sequence number with which the operation stops for the
sequence number comparison and stop function and the number of the
program to which the sequence number belongs
Setting of mirror image ON/OFF for each axes.
0 : Mirror image off
1 : Mirror image on
Page key
PAGE
or
PAGE
can also be pressed to display the SETTING
(TIMER) screen. See subsection 11.4.6 for this screen.
Contents of settings
D PARAMETER WRITE
D TV CHECK
D PUNCH CODE
D INPUT UNIT
D I/O CHANNEL
D SEQUENCE STOP
D SEQUENCE STOP
D MIRROR IMAGE
D Others
