OPERATION11. SETTING AND DISPLAYING DATA
Displays the workpiece origin offset for each workpiece coordinate
system (G54 to G59) and external workpiece origin offset. The workpiece
origin offset and external workpiece origin offset can be set on this screen.
Procedure for Displaying and Setting the Workpiece Origin Offset Value
1 Press function key
2 Press chapter selection soft key
The workpiece coordinate system setting screen is displayed.
02 X 152.580
(G55) Y 234.000
03 X 300.000
(G56) Y 200.000
> _ S 0 T0000
MDI **** *** *** 16:05:59
[ OFFSET ][ SETING ][ WORK ][ ][ (OPRT) ]
00 X 0.000
(EXT) Y 0.000
01 X 20.000
(G54) Y 50.000
WORK COORDINATES O0001 N00000
3 The screen for displaying the workpiece origin offset values consists
of two or more pages. Display a desired page in either of the
following two ways:
3–1 Press the page up
or page down
3–2 Enter the workpiece coordinate system number (0:external
workpiece origin offset, 1 to 6: workpiece coordinate systems
G54 to G59) and press operation selection soft key
4 Turn off the data protection key to enable writing.
5 Move the cursor to the workpiece origin offset to be changed.
6 Enter a desired value by pressing numeric keys, then press soft key
[INPUT]. The entered value is specified in the the workpiece origin
offset value. Or, by entering a desired value with numeric keys and
pressing soft key
[+INPUT], the entered value can be added to the
previous offset value.
7 Repeat 5 and 6 to change other offset values.
8 Turn on the data protection key to disable writing.
Displaying and Setting
the Workpiece Origin
