11. SETTING AND DISPLAYING DATA
The program number, sequence number, and current CNC status are
always displayed on the screen except when the power is turned on, a
system alarm occurs, or the PMC screen is displayed.
If data setting or the input/output operation is incorrect, the CNC does not
accept the operation and displays a warning message.
This section describes the display of the program number, sequence
number, and status, and warning messages displayed for incorrect data
setting or input/output operation.
The program number and sequence number are displayed at the top right
on the screen as shown below.
PROGRAM O1000 N00000
N100 G92 G00 X1270 Y1270. ;
N110 G90 G00 X15. Y15. T02 ;
N120 X1085. Y15. ;
N130 X1085. Y635. ;
N140 X15. Y635. ;
N200 G72 X150. Y80. ;
N210 G76 I40. J0 K4 T03 ;
N300 G72 X400. Y80. ;
N310 G76 I40. J0 K7 ;
N400 G72 X770. Y80. ;
EDIT **** *** *** 15:05:41
[ PRGRM ][ LIB ][ ][ C.A.P. ][ (OPRT) ]
The program number and sequence number displayed depend on the
screen and are given below:
On the program screen in the EDIT mode on Background edit screen :
The program No. being edited and the sequence number just prior to the
cursor are indicated.
Other than above screens :
The program No. and the sequence No. executed last are indicated.
Immediately after program number search or sequence number
Immediately after the program No. search and sequence No. search, the
program No. and the sequence No. searched are indicated.
DATA SETTING OR
Displaying the Program
Number and Sequence
