hh:mm:ss – Hours, minutes, and seconds
INPUT : Indicates that data is being input.
OUTPUT : Indicates that data is being output.
SRCH : Indicates that a search is being performed.
EDIT : Indicates that another editing operation is being performed
(insertion, modification, etc.)
LSK : Indicates that labels are skipped when data is input.
RSTR : Indicates that the program is being restarte.
Space : Indicates that no editing operation is being performed.
When invalid data is entered (wrong format, value out of range, etc.),
when input is disabled (wrong mode, write disabled, etc.), or when
input/output operation is incorrect (wrong mode, etc.), a warning message
is displayed. In this case, the CNC does not accept the setting or
input/output operation (retry the operation according to the message).
The following are examples of warning messages:
(Display sof tkeys)
Example 1)
When a parameter is entered
> 1
EDIT WRONG MODE
(Display soft keys)
Example 2)
When a parameter is entered
> 999999999
MDI TOO MANY DIGITS
(Display soft keys)
Example 3)
When a parameter is output to an external input/output device
> _
MEM WRONG MODE
(7) Current time
(8) Program editing status
(9) Warning for data setting
or input/output operation
