5. FEED FUNCTIONS
Those parameters related to automatic corner deceleration in advanced
preview control mode are shown below.
Switching the methods for automatic corner de-
Lower limit of feedrate in automatic corner decel-
eration based on the angle
Limit angle in corner deceleration based on the
This function cannot be enabled for a single block or during dry run.
This function decelerates the feedrate when the difference between the
feedrates at the end point of block A and the start point of block B along
each axis is larger than the value specified in parameter No. 1781. The
function executes block B when the feedrates along all axes are smaller
than the feedrate specified in parameter No. 1741. In this case, the
function determines that the number of accumulated pulses is zero.
The flowchart for feedrate control is shown below.
Is the feedrate difference between
blocks along each axis larger than
the value specified in parameter
Are the feedrates along all axes
smaller than that specified in
parameter No. 1741?
Further decelerates the
feedrate in block A
The number of accumulated pulses
is determined to be zero and block
B is executed
D Advanced preview
according to the feedrate
blocks along each axis
D Flowchart for feedrate
