Series 16i/18i/160i/180i - PB Connection manual (Function) Page 118

Connection manual (Function)
5. TOOL FUNCTION (T FUNCTION)
B–63683EN/01
108
#7
16283
#6 #5 #4 #3 #2
MY4
#1
MX4
#0
[Data type] Bit
This parameter is valid when the function used to set tool data is specified.
In the following description, m represents the number of subtools stored
for a multi–tool.
MX4 For the tool position compensation value along the X–axis for a
multi–tool:
0 : m four–byte values can be specified. The valid data range is 0 to
"99999999.
1 : m two–byte values can be specified. The valid data range is –32768 to
+32767.
MY4 For the tool position compensation value along the Y–axis for a
multi–tool:
0 : m four–byte values can be specified. The valid data range is 0 to
"99999999.
1 : m two–byte values can be specified. The valid data range is –32768 to
+32767.
16284 Number of tools to be stored
[Data type] Word
[Valid data range] 0 or later
This parameter specifies the number of tools to be stored for the function
used to set tool data.
The number beyond 16KB cannot be set as an amount of data.
16285 Number of digits in the tool number of an subtool for a multi–tool
[Data type] Word
[Valid data range] 0 to 4
This parameter specifies the number of digits that can be specified for the
tool number of an subtool for which multiple tool control is executed by
the function used to set tool data.
16286 Number of subtools for a multi–tool
[Data type] Word
[Valid data range] 0 or later
This parameter specifies the number of subtools for which multiple tool
control is executed by the function used to set tool data.
The number beyond 16KB cannot be set in accordance with the setting
value of the parameter 16284 as an amount of data.
