Series 16i/18i/160i/180i - PB Connection manual (Function) Page 85

Connection manual (Function)
B–63683EN/01
4. FUNCTIONS TO SIMPLIFY PROGRAMMING
75
16206 Machining pattern when multiple workpieces are taken
[Data type] Byte
[Valid data range] 0 to 3
Parameter 16206 sets a machining pattern when multiple workpieces are
taken.
0 : A program without the G73 or G74 command for machining when
multiple workpieces are taken is used.
NOTE
Alarm 4539 is issued if the G73 or G74 command is found
with this setting.
1 : A program containing the G73 or G74 command is used and test
machining is executed.
2 : A program containing the G73 or G74 command is used and the
remaining processing is executed after test machining.
3 : A program containing the G73 or G74 command is used and the entire
machining is executed.
16228 Number of character that can be stored for a U or V macro function
[Data type] Byte
Setting Value Number of macro storage characters
0 3200
1 11008
2 22272
3 27072
[Valid data range]
