Servo Motor Beta Series (I/O Link Option) Maintenance manual Page 266

Maintenance manual
Edit.
3/13
Date Signature Change
FANUC SERVO MOTOR BETA series I/O
Link Option Add function in edition 09
B-65245EN/02-01
1. Parameter setting of rapid traverse override feedrate
1.1.
1.1.1.1.
1.1.
Outline
Outline Outline
Outline
The specifications for the rapid traverse override 100% and F0 is the same as before. In the
new specifications, the feedrate of the rapid traverse override 50% and 25% can be specified by
the parameter.
1.2.
1.2.1.2.
1.2.
Parameter
Parameter Parameter
Parameter
No #7 #6 #5 #4 #3 #2 #1 #0
002 RVF2
Size
SizeSize
Size : 1 byte (bit type)
RVF2
RVF2RVF2
RVF2 The feedrate of rapid traverse override is specified by four steps
0 : with 100%, 50%, 25% and F0.
1 : with 100%, F1, F2 and F0.
The relation between the rapid traverse override signals ROV1, ROV2 and the actual
override value is shown in the following table.
Actual override value
ROV2 ROV1
RVF2=0 RVF2=1
0 0 100% 100%
0 1 50% F1
1 0 25% F2
1 1 F0 F0
NOTE
The feedrate in F2, F1 and F0 must be specified the actual feedrate in the parameter.
