PROGRAMMING5. FEED FUNCTIONS
N1 N2 t
Without corner deceleration
With corner deceleration
at the corner
The allowable feedrate difference can be specified for each axis in
parameter No. 1783.
The feedrate difference is also checked during dry–run operation or
during deceleration caused by an external signal, using feedrate
commands specified in a program.
When G90 (exact stop) is specified, exact stop is performed irrespective
of the parameter settings.
If an override is changed during operation, the feedrate difference will
not be checked correctly.
D Setting the allowable
feedrate difference along
D Checking the feedrate
D Exact stop
