PROGRAMMING
B–63664EN/02
7. COORDINATE SYSTEM
97
Besides the six workpiece coordinate systems (standard workpiece
coordinate systems) selectable with G54 to G59, 48 additional workpiece
coordinate systems (additional workpiece coordinate systems) can be
used. Alternatively, up to 300 additional workpiece coordinate systems
can be used.
G54.1Pn ; or G54Pn ;
Pn : Codes specifying the additional workpiece coordinate systems
n : 1 to 48 or 1 to 300
G10L20 Pn IP _;
Pn : Codes specifying the workpiece coordinate system for setting
the workpiece zero point offset value
n : 1 to 48 or 1 to 300
IP_ : Axis addresses and a value set as the workpiece zero point
offset
IP
IP
When a P code is specified together with G54.1 (G54), the corresponding
coordinate system is selected from the additional workpiece coordinate
systems (1 to 48 or 1 to 300).
A workpiece coordinate system, once selected, is valid until another
workpiece coordinate system is selected. Standard workpiece coordinate
system 1 (selectable with G54) is selected at power–on.
G54.1 P1 Additional workpiece coordinate system 1......
G54.1 P2 Additional workpiece coordinate system 2......
G54.1 P48 Additional workpiece coordinate system 48.....
G54.1 P300 Additional workpiece coordinate system 300....
As with the standard workpiece coordinate systems, the following
operations can be performed for a workpiece zero point offset in an
additional workpiece coordinate system:
(1)The
OFFSET function key can be used to display and set a workpiece
zero point offset value.
(2)The G10 function enables a workpiece zero point offset value to be set
by programming (refer to
II–7.2.3).
(3)A custom macro allows a workpiece zero point offset value to be
handled as a system variable.
(4)Workpiece zero point offset data can be entered or output as external
data.
(5)The PMC window function enables workpiece zero point offset data
to be read as program command modal data.
7.2.5
Adding Workpiece
Coordinate Systems
(G54.1
or G54)
Format
D Selecting the additional
workpiece coordinate
systems
D Setting the workpiece
zero point offset value
in the additional
workpiece coordinate
systems
Explanations
D Selecting the additional
workpiece coordinate
systems
