16i/160i-LB Operators manual Page 264

Operators manual

Page of 912

/ 912

PROGRAMMING

13. CUSTOM MACRO

B–63664EN/02

240

Position information cannot be written but can be read.

Table 13.2 (k) System variables for position information

Variable

number

Position

information

Coordinate

system

Cutter com-

pensation

value

Read

operation

during

movement

#5001–#5008 Block end point Workpiece

coordinate

system

Not

included

Enabled

#5021–#5028 Current position Machine

coordinate

system

Included

Disabled

#5041–#5048 Current position

Workpiece

coordinate

#5061–#5068 Skip signal posi-

tion

coordinate

system

Enabled

#5101–#5108 Deviated servo

position

Disabled

S The first digit (from 1 to 8) represents an axis number.

S The nozzle position where the skip signal is turned on in a G31 (skip

function) block is held in variables #5061 to #5068. When the skip

signal is not turned on in a G31 block, the end point of the specified

block is held in these variables.

S When read during movement is ”disabled,” this means that expected

values cannot be read due to the buffering (preread) function.

D Current position

Contents Summary of 16i/160i-LB Operators manual
