PROGRAMMING18. SPECIFYING THE LASER FUNCTION

B–63664EN/02

352

Step Step power

distance

12345678910

301

Up 00.000 0000 0000 0000 0000 0000 0000 0000 0000 0000 0000

301 Down 00.000 0000 0000 0000 0000 0000 0000 0000 0000 0000 0000

302 Up 00.000 0000 0000 0000 0000 0000 0000 0000 0000 0000 0000

302 Down 00.000 0000 0000 0000 0000 0000 0000 0000 0000 0000 0000

303 Up 00.000 0000 0000 0000 0000 0000 0000 0000 0000 0000 0000

303 Down 00.000 0000 0000 0000 0000 0000 0000 0000 0000 0000 0000

304 Up 00.000 0000 0000 0000 0000 0000 0000 0000 0000 0000 0000

304 Down 00.000 0000 0000 0000 0000 0000 0000 0000 0000 0000 0000

305 Up 00.000 0000 0000 0000 0000 0000 0000 0000 0000 0000 0000

305 Down 00.000 0000 0000 0000 0000 0000 0000 0000 0000 0000 0000

The valid data ranges are as follows:

Ramp UP/DOWN step distance : 0 to 65.000 mm

Step power : 0 to 7000 W

Ramp UP/DOWN operation is performed by measuring the distance of

the straight line from the machining start point to the machining end point

in a single cutting block.

The number of steps in which the laser power is changed in step control

is 10. This number is fixed.

On the CNC, the data area for step control is reserved, but the screen for

setting the machining conditions is not provided. Access the data area

using C language function of a PMC.

In a machining program, step control mode is set by specifying command

E301 to E305. Only the laser power

is changed in step control mode; the

other machining conditions set with the previously specified E1 to E10

commands remain as is.

The ramp UP and DOWN distances cannot extend over multiple blocks.

Power override is effective for the laser power output in step control.

For an arc, step control is possible if the distance of the straight line from

the start and end points is longer than the sum of the ramp UP and DOWN

distances. A full circle, on which the start and end points are the same,

does not satisfy this condition and, therefore, step control is not possible.

If, however, the circle is divided in a machining program, step control can

be performed on each part of the full circle.

If, in the machining block subject to step control, the remaining amount

of movement becomes shorter than the DOWN distance before the

movement along the ramp UP distance is completed, an alarm is issued.

An alarm is also issued if movement along the ramp UP distance is not

completed in the single block.

Alarm No. Message (Japanese/English)

4131 Invalid step distance/STEP LENGTH

D Valid data ranges

D Number of steps

D Writing to and reading

from the data area

D Step control mode

D Step distances

D Power override

D Operation on arcs

D Alarm
