PROGRAMMING18. SPECIFYING THE LASER FUNCTION
B–63664EN/02
354
In step control mode, only the laser power is changed according to the set
distances; other conditions such as the frequency, duty, and feedrate are
not changed. The data effective at that time is inherited. After the 10th
step, where ramp UP operation ends, the laser power is held constant. That
is, the laser power assumed at the 10th step remains effective until ramp
DOWN operation starts. If, during ramp UP or ramp DOWN operation,
the amount of movement in one interpolation period in the CNC is larger
than the distance for one step, the power may not be changed accurately
in ten steps. Should this occur, adjustment is required with the ramp
distance per step, feedrate, time constant, or bit 7 of parameter No. 15008.
#7
RMP15008
#6 #5 #4 #3 #2 #1 #0
RMP In the step function,
0 : Measures the movement distance with the UP/DOWN step distances
only.
1 : Measures the movement distance with the UP/DOWN step and the
specified feed rate.
15730 Distance for one step during ramp UP operation
[Data format] Word
[Data unit] 1/1000 mm
[Data range] 0 to 65000
Sets the distance for one step during ramp UP operation in step control.
15731 Ramp UP step power 1
15732 Ramp UP step power 2
15733 Ramp UP step power 3
15734 Ramp UP step power 4
15735 Ramp UP step power 5
15736 Ramp UP step power 6
15737 Ramp UP step power 7
15738 Ramp UP step power 8
15739 Ramp UP step power 9
15740 Ramp UP step power 10
[Data format] Word
[Data unit] W
[Data range] 0 to 7000
Sets the laser power for each step during ramp UP operation in step
control.
Parameter
