PROGRAMMING 18. SPECIFYING THE LASER FUNCTION

B–63664EN/02

355

15745 Distance for one step during ramp DOWN operation

[Data format] Word

[Data unit] 1/1000 mm

[Data range] 0 to 65000

Sets the distance for one step during ramp DOWN operation in step

control.

15746 Ramp DOWN step power 1

15747 Ramp DOWN step power 2

15748 Ramp DOWN step power 3

15749 Ramp DOWN step power 4

15750 Ramp DOWN step power 5

15751 Ramp DOWN step power 6

15752 Ramp DOWN step power 7

15753 Ramp DOWN step power 8

15754 Ramp DOWN step power 9

15755 Ramp DOWN step power 10

[Data format] Word

[Data unit] W

[Data range] 0 to 7000

Sets the laser power for each step during ramp UP operation in step

control.

S This function is an option function, and requires the following separate

functions:

1) Option function, ”machining condition setting function”

2) Option function, ”expansion retention type memory add function”

S This function can be used to its full advantage when used with the

FANUC C series laser.

S This function cannot be used with the automatic corner override

function, edge machining function, and startup machining function.

The step function takes precedence.

S This function is not effective when the single block, dry run, or

machine lock function is used.

S This function can be used together only with X–Y plane facing.

It cannot be used together with any other function (such as cylindrical

interpolation, normal–direction control, or three–dimensional

cutting).

S The sample programs, machining conditions, and other information

described in this manual do not represent actual machining conditions.

S The information described in this manual is subject to change without

notice.

Limitations
