PROGRAMMING18. SPECIFYING THE LASER FUNCTION
An M code for transferring a comment is provided.
This code can be set in parameter No. 15350.
Use of this M code allows a comment consisting of up to 24 alphanumeric
characters to be posted to the PMC via the window function.
In a comment, the material of a workpiece can be specified.
Within 24 characters including alphabetical
characters, numeric characters, a decimal point, and
where, xxx represents the value set in parameter No. 15350.
G92X_Y_Z; : Sets a coordinate system.
E1; : Specifies a machining data set number.
E101; : Specifies a piercing data set number.
M200; [Macro call]
G32L2; : Opens the assist gas start shutter according to the data of
G24; : Performs piercing according to the data of E101.
G32L1; ; Switches the assist gas according to the data of E001.
G01X_Y_; : Executes start–up machining if an auxiliary data set
number is set in the item of start–up machining selection
X_Y_; : Performs cutting according to the data set of E001.
M201; [Macro call]
G32L0; : Stops the output of assist gas, and closes the shutter.
M30; : Ends the program.
Reading a Comment
