PROGRAMMING18. SPECIFYING THE LASER FUNCTION
This setting is ignored if bit 0 of parameter No. 15011 is set
CSC In the startup machining mode, when S, P, Q, or F is specified at the same
time in the first G01, G02, or G03 block that appears after G24:
0 : Startup machining is performed in the conventional manner,
regardless of the S, P, Q, or F command.
1 : The startup machining is canceled, and cutting is performed with the
specified S, P, Q, or F value.
#6 #5 #4
#3 #2 #1 #0
[Data type] Bit
CVA The angle in the edge machining function is:
0 : Determined according to the setting of bit 3 of parameter No. 15007.
1 : Determined by the programmed path regardless of the setting of bit 3
of parameter No. 15007.
EXS When the edge machining function is executed, switching to the piercing
conditions is performed:
0 : Upon completion of distribution (if bit 2 of parameter No. 15007 is set
to 0), or at the end of acceleration/deceleration (if bit 2 of parameter
No. 15007 is set to 1).
1 : After the in–position check for all axes has been made.
15059 return peak value
[Data type] Word
[Unit of data ] W
[Valid data range] 0 to 7000
At the time of startup from a corner during edge machining, the return
feedrate, return frequency, and return duty cycle are used for operation
until movement is made over the distance set as the return distance, but
the output peak value used for operation is a programmed value.
When a value is set as the return peak value, this setting is used for
operation instead of the programmed value.
The edge machining function determines the angle between two cutting
blocks to perform machining at the start of the latter block according to
the set machining conditions. On the other hand, when movement is made
from G24 (piercing) to a cutting block, the startup machining function
machines the set return distance according to the set machining
