PROGRAMMING18. SPECIFYING THE LASER FUNCTION

B–63664EN/02

378

15091 Minimum pulse frequency

[Unit of data ] Hz

[Valid data range] 5 to 2000

This parameter specifies a minimum pulse frequency clamp value. If the

frequency calculated from the current feedrate becomes lower than the

value set in this parameter, the frequency is clamped to the value set in this

parameter.

15092 Minimum pulse duty cycle

[Unit of data ] %

[Valid data range] 0 to 100

This parameter specifies a minimum pulse duty cycle clamp value. If the

duty cycle calculated from the current feedrate becomes lower than the

value set in this parameter, the duty cycle is clamped to the value set in

this parameter.

15094 Power control filter time constant

[Unit of data ] ms

[Valid data range] 8 to 32767

This parameter specifies a time constant for the primary delay filter used

to delay the power command for synchronization with machine feed.

The primary delay filter is expressed as follows:

+ O

n–1

) (I

–O

n–1

)

Ts: 8 ms (sampling time)

Tc: To be set in this parameter (time constant)

15095 Allowable variation in power control speed

[Unit of data ] mm/min

[Valid data range] 0 to 255

The calculated feedrate slightly fluctuates also in a steady state, and the

data items (specified power, pulse frequency, and pulse duty) calculated

based on the feedrate also fluctuate. To prevent these unnecessary

fluctuations, specify the width of a dead zone for feedrate fluctuations.
