PROGRAMMING 18. SPECIFYING THE LASER FUNCTION
The beam delay control function controls the laser output timing
according to the delay in the machine.
The beam output timing can be delayed according to the delay timing set
in parameter No. 15219.
In the AI contour control mode and AI nano contour control mode, control
is performed with a shorter processing period than the processing period
used in the normal mode to enhance reduction of variation in machining
For details of the beam delay control function, see Section 18.4.
X, Y Specified position
Conceptual diagram of beam delay control
In the AI contour control mode and AI nano contour control mode, the
execution of programmed laser output commands is controlled at shorter
processing intervals than in the normal mode. Even when laser machining
is performed at high speed, high precision is attained.
#4 #3 #2 #1 #0
MI1, MI0 Set the batch transfer quantity in the AI contour control mode and AI nano
contour control mode.
MI1 MI0 Batch transfer quantity
0 0 1
0 1 2
1 0 4
D Beam delay control
D Beam on/off control
